Product Overview
HC-1530 is a water-soluble dry film photoresist designed for flexible PCB and flexible circuit board manufacturing. It offers strong adhesion, high resolution, excellent photosensitivity, and stable exposure performance, supporting reliable pattern formation and efficient processing for flexible circuit applications. Its water-soluble development system enables clean and efficient processing.
Technical Specifications
| Properties | Parameters |
|---|---|
| Thickness | 30um |
| Exposure Energy(SST=7/21) | 60mJ/cm2 |
| Sensitivity (21ST) | 7土1 |
| Resolution(SST=6/21) | 35um |
| Adhesion(SST=6/21) | 40um |
| Stripping Time (3%NaOH, 50° C) | 55s |
Key Features
High Resolution
Supports precise pattern formation for flexible PCB and flexible circuit board applications.
Excellent Photosensitivity
Provides consistent exposure performance for accurate image transfer and stable pattern definition.
Strong Adhesion
Provides good adhesion to flexible substrates, helping maintain pattern integrity throughout the manufacturing process.
Stable Exposure Performance
Supports consistent imaging results and efficient processing in flexible circuit manufacturing.
Water-Soluble Development
Designed for water-soluble development to support efficient and clean processing.
